產品特點

1.全通徑 Full Port
2.150磅法蘭連接 ANSI 150LB Flange Connection
3.連接尺寸 Size: 1 /2" to 8" (DN15-200)
4.閥體材質 Valve Body Material:Stainless Steel   AISI-316(EN10213 1.4408)(ASTM-A351-CF8M)   AISI-304(EN10213 1 .4308)(ASTM-A351-CF8)
5.防火設計 Fire-Safe Design
6.采用ISO5211直接安裝執行器平臺設計 IS0 5211 Direct Mounting Pad
7.帶鎖定功能手柄 locking device handle
8.閥桿防靜電設計 Anti-Static Devices for ball-stem-body
9.閥桿防脫出設計 Blow-out proof stem
10.球槽上有泄壓孔設計 Pressure balance hole in ball slot

技術參數

1.設計生產標準：basic Design And Manufacture According To ANSI B16.34
2.結構長度：face-to Face According To ANSI B16.10
3.法蘭連接標準：flange Ends According To ANSI B16.5
4.檢測標準：inspection And Tested According To Api598
